| Bridgeport SeriesI Vertical Mill | |
|---|---|
| Make | Bridgeport |
| Model No. | Series I |
| Country of Origin: | USA |
| Serial # | 12/BR 221468 |
| Condition | Very Good |
- Bridgeport SeriesI Vertical Mill Features:
- Infinitely Variable Spindle Speeds.
- Bijur Lubrication System.
- Bridgeport X-Axis Power Feed (needs switch handle).
- Control Panel.
- Bijur Spraymist Coolant System.
- Bridgeport SeriesI Vertical Mill Specifications:
- Work Table:
- Surface Area: 48″ x 9″
- T-Slot Center Distance: 3 @ 2.5″ centers
- T-Slot Sizes: 0.625″
- Maximum Weight of Workpiece: 750 lbs.
- Travels:
- X-Axis Table Travel: 36″
- Y-Axis Table Travel: 12″
- Z-Axis Table Travel (knee): 16″
- Quill Travel: 5″
- Ram Travel: 12″
- Spindle:
- Spindle Taper: R8
- Spindle Diameter: 1.875″
- Quill Diameter: 3.375″
- Distance Spindle to Table (minimum / maximum): 2-1/2″ to 18-1/4″
- Distance Spindle to Column (minimum / maximum): 6-3/4″ to 18-3/4″
- Speeds: 60 to 4,200 RPM
- Power Quill Feed: 0.0015″/rev, 0.003″/rev & 0.006″/rev
- Motor: 2 Horsepower, 220 / 230 / 440 / 460 Volt, 1,415 / 1,710 RPM, 50 / 60 Hz
- Head Adjustments:
- Head Swivel: 360 degrees
- Head Cant: 45 degrees
- Head Tilt: 90 degrees
- General:
- Electrical: 220 / 230 / 440 / 460 Volt, Three Phase
- Overall Dimensions: 68″ x 64″ x 84″ tall
Bridgeport SeriesI Vertical Mill Comes as shown in pictures.
