OKUMA ES-L10 CNC TURNING CENTER | |
---|---|
Make | Okuma |
Model No. | ES-L10 |
Year | 2004 |
Serial # | P0127 |
Condition | Very Good |
All specifications are approximations and are subject to verification.
“This machine is in very Good running condition. It is equipped with 10″ Big Bore Chuck, Tailstock & chip conveyor. On Our Floor fully powered / tested & is in Great working condition.”
- Okuma ES-L10 Equipped With:
- 12-Station Turret
- OSP-U10L CNC Control
- One Touch IGF Programming
- Floppy Drive
- 10″ Kitagawa Hydraulic Chuck
- Hydraulic Tailstock with Power Quill
- Chip Pan and Chip Conveyor
- Coolant System
- Automatic Lubrication system
- Foot Operated Control for Chuck and Tailstock
- Okuma ES-L10 Specifications:
- Max Turning Diameter: 12.20″
- Max Turning Length: 19.68″
- Max Bar Capacity: 3.05″
- Swing Over Bed: 21.65″
- Distance Between Centers: 24.6″
- Travel:
- X Axis Travel: 8.10″
- Z Axis Travel: 20.47″
- Rapid Traverse X Axis: 787 IPM
- Rapid Traverse Z Axis: 984 IPM
- Spindle:
- Spindle Nose: A2-8
- Spindle Bore: 3.15″
- Spindle Speed: 30-3000 RPM
- Spindle Motor: 20 HP
- Turret:
- Turret Capacity: 12 Stations
- Turret Index Time: 0.5 Second
- Tailstock:
- Tailstock Body Travel: 14.3″
- Tailstock Quill Dia.: 3.54″
- Tailstock Quill Stroke: 3.93″
- Tailstock Taper: MT-5
- General:
- Power Source: AC 220 V, Three Phase, 60 Hz
- Power Requirement: 68 Amps
- Overall Dimensions: 110″ x 68″ x 80″ High
- Overall Dimensions: 140″ x 68″ x 80″ High with Chip Conveyor
- Weight : 8500 lbs Approx.
Okuma ES-L10 comes as shown in Pictures…..
