*All specifications are approximations and are subject to verification. Comes as shown in the images. Additionally, please give us a call if you have any questions before purchasing. All sales are final.*
| Make: |
TSUGAMI |
| Model: |
B0205-III |
| Year: |
2015 |
| Condition: |
Used – Good |
| Equipped With: |
- Fanuc Oi-TD CNC Control
- Controlled Axes (Liner Axes) X1, X2, Y1, Z1, Z2
- Comes with Edge Minuteman 320 SE Bar Feeder
- C & Y Axis Capable
- Live Tools Capable
- Long Parts Capable
- MPG Handwheel Control
- Part Catcher
- Main & Back Spindle Synchronization
- High Speed Rapid Travers: 944 IPM
- High Speed Program Processing
- Absolute Position Detection
- Automatic Lubrication System
- Coolant Tank
- Leveling Pads
- Books and Manuals
|
| Capacity: |
- Max Turning Diameter: 0.79″ (20 mm)
- Max Turning Length: 8.3″ (210 mm)
- Max Turning Length with Gripping Unit: 6.69″ (170mm)
- Max Bar Capacity: 0.79″ (20 mm)
- Max Tool Positions: 21
- Max. Main Spindle Drilling Diameter: 0.39″ (10 mm)
- Max. Main Spindle Tapping Diameter: M10
- Max. Back Spindle Chucking Diameter: 0.79″ (20 mm)
- Max. Back Spindle Drilling Diameter: 0.31″ (8 mm)
- Max. Back Spindle Tapping Diameter: M8
- Max. Cross Drilling Diameter: 0.275 ( 7 mm)/ER11 and 0.393″ (10 mm)/ER16
- Max. Cross Tapping Diameter: M5 x 0.8 (option)
- Max. Tool Spindle Slotting Cutter Diameter: 1.18″ (30 mm)
- Max. Back Drilling Diameter: 0.275″ (7 mm)
- Max. Back Tapping Diameter: M5
|
| Spindle: |
- Main Spindle Indexing: 360° (Full C-Axis)
- Main Spindle Bore: 0.79″ (20 mm)
- Main Spindle Speed: 10000 RPM
- Back Spindle Motor: 3.7 kw
- Back Spindle Indexing: 360° (Full C-Axis)
- Back Spindle Speed: 12000 RPM
- Back Spindle Motor: 2.2 kw
|
| Standard Tools: |
- OD Tools: 9
- Stationary Tools For Front Spindle: 4
- Stationary Tools For Back Spindle: 4
|
| Power Driven Tools Attachment: |
- Power Driven Tools: 4
- Driven Tool Speed: 8000 RPM
- Driven Tool Motor: 1.2 kw
|
| General: |
- Power Source: AC 220v / 3-Phase /60 Hz
- Power Requirement: 11 kva
- Overall Dimensions: 65.16″ X 44.29″ X 66.93″ High without Bar Feeder
- Weight: 4409 lbs. Approx.
|
