HAAS VF-4 Vertical Machining Centre
Out of stock
SKU: |
1979 |
Make/Model: |
Haas/VF-4 |
Video: |
[fusion_button link=”https://www.youtube.com/watch?v=JP6q7NTtZ1Y” title=”” target=”lightbox” link_attributes=”” alignment_medium=”” alignment_small=”” alignment=”center” modal=”” hide_on_mobile=”small-visibility,medium-visibility,large-visibility” sticky_display=”normal,sticky” class=”” id=”” color=”default” button_gradient_top_color_hover=”” hue=”” saturation=”” lightness=”” alpha=”” button_gradient_top_color=”” button_gradient_bottom_color_hover=”” button_gradient_bottom_color=”” gradient_start_position=”” gradient_end_position=”” gradient_type=”” radial_direction=”” linear_angle=”180″ accent_hover_color=”” accent_color=”” type=”” bevel_color=”” bevel_color_hover=”” border_top=”” border_right=”” border_bottom=”” border_left=”” border_radius_top_left=”” border_radius_top_right=”” border_radius_bottom_right=”” border_radius_bottom_left=”” border_hover_color=”” border_color=”” size=”” padding_top=”” padding_right=”” padding_bottom=”” padding_left=”” fusion_font_family_button_font=”” fusion_font_variant_button_font=”” font_size=”” line_height=”” letter_spacing=”” text_transform=”” stretch=”yes” margin_top=”” margin_right=”” margin_bottom=”” margin_left=”” icon=”fa-play-circle fas” icon_position=”left” icon_divider=”no” hover_transition=”none” animation_type=”” animation_direction=”left” animation_color=”” animation_speed=”0.3″ animation_delay=”0″ animation_offset=””]Play Video[/fusion_button] |
- HAAS VF-4 Features:
- Haas CNC Control
- 7500 RPM Spindle
- NIKKEN TRUNNION
- MPG Control
- 24 + 1 Automatic Side Mount tool changer
- MPG Control with Display
- Wireless Probing system Ready
- High Speed Machining
- USB DriveExpanded Memory
- Rigid Tapping
- Advanced Tool Management
- Power Failure Detection Module
- User Definable Macros
- Spindle Orientation
- Coordinate Rotational Scaling
- Brush-type servo drive motors on all axis
- Programmable coolant
- Telescopic way covers
- Chip auger
- HAAS VF-4 Specifications:
- Travels:
- X-Axis: 40″
- Y-Axis: 26″
- Z-Axis: 25″
- Rapid Traverse Rates: 710 Inch Per Minute
- Cutting Feed Rates: 500 Inch Per Minute
- Spindle Nose to Table (Min.- Max.): 4″ – 29″
- Table:
- Length: 54″
- Width: 25″
- Die Mold Jig Table
- Max Weight on Table: 4000 lbs
- Spindle:
- Taper Size: 40
- Speed Range: 12,000 RPM
- Spindle Power: 30 HP
- Automatic Tool Changer:
- Capacity: 24 Side Mount
- Max Tool Weight: 12 lbs
- Max Tool Dia: 5″
- Max Tool Length: 13″
- Tool Changing Time: 2.6 Seconds
- General:
- Air Required: 100 psi, 4 scfm
- Power: 220v / 66FLA / 3-Phase
- Overall Dimensions: 125″ x 93″ x 102″ High
- Weight: 15300 lbs
