Enshu VMC-650 CNC Vertical Machining Center

Enshu VMC-650 CNC Vertical Machining Center

Out of stock

On our Floor fully working. This Mill has Gearhead 50 Taper 4000 RPM Spindle, 30 tool Side Mount Tool changer, Fanuc Control, 12544 Cutting hours for the age. feel free to contact us for more Pictures & Video.

SKU: 1764 Category:

Description

ENSHU VMC-650 CNC VERTICAL MACHINING CENTER
MakeENSHU
Model No.VMC-650
Year1988
Serial #249
ConditionVery Good
  • Enshu VMC-650 Features:
  • Heavy Box Way Japanese Construction
  • Fanuc 11M CNC Control
  • High Precision 4,000 RPM Spindle
  • 50 Taper Geared Head Spindle
  • 30 Tools Side Mount Bidirectional Tool Changer
  • Powerful 30 hp high torque spindle motor
  • Spindle Orientation
  • Fast Rapid Traverse Rate
  • Coolant with large separate coolant tank
  • Spindle Chiller
  • Enshu VMC-650 Specifications:
  • Travels:
  • X-Axis: 51.2″
  • Y-Axis: 25.6″
  • Z-Axis: 22.0″
  • Table:
  • Length: 63.0″
  • Width: 2356″
  • Max Weight on Table: 3300 lbs
  • T-Slot no. & Width: 6 X 0.7″
  • Gear Head Spindle:
  • Taper Size: CAT-50
  • Speed Range: 40 – 4,000 RPM
  • Spindle Power: 30 HP
  • Feed rates:
  • Rapid X,Y & Z: 630 inch/Per Minute
  • Cutting Feedrate: 450″ inch/ Per Minute
  • Automatic Tool Changer:
  • 50 Taper
  • Capacity: 30
  • Max Tool Weight: 31.6 lbs
  • Max Tool Length: 11.8″
  • Max Tool Dia.: 4.9″
  • General:
  • Air Required: 90 psi, 4 scfm
  • Power: 205-220v / 50kva / 3-Phase
  • Overall Dimensions: 150″ x 115″ x 118″ High
  • Weight: 26000 lbs

Enshu VMC-650 Comes as shown in pictures.
