Haas Mini Mill CNC Vertical Machining Center

SKU 11483

Make/Model Haas Mini Mill

Year 2001

Video On Request

Out of stock

SKU:	11483
Make/Model:	Haas Mini Mill
Year:	2001
Video:	On Request

SKU: 11483

*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*

Make:	Haas
Model:	Mini Mill
Year:	2001
Machine Type:	CNC Vertical Machining Center
Control:	Haas CNC Control
Country of Origin:	USA

Equipped With:
Haas CNC Control
CAT-40 Taper Spindle
Automatic Tool Changer
Rigid Tapping
Coolant System
Electronic Handwheel
Programmable Spindle Speeds
Full Enclosure
Compact Footprint Design

Table:
Table Size: 36″ x 12″
Max Table Load: 500 LBS
T-Slots: 3
T-Slot Width: 5/8″

Travels:
X-Axis Travel: 16″
Y-Axis Travel: 12″
Z-Axis Travel: 10″

Spindle:
Spindle Taper: CAT-40
Spindle Speed: 6,000 RPM
Spindle Motor: 7.5 HP
Drive Type: Direct Drive

Automatic Tool Changer:
ATC Capacity: 10 Stations
Tool Change Type: Automatic
Max Tool Diameter: Approx. 3″
Max Tool Weight: Approx. 12 LBS

Feed Rates:
Rapid Traverse Rate: Approx. 710 IPM
Cutting Feed Rate: Programmable

Electrical:
Power Requirement: 220V / 3-Phase / 60 Hz
Air Requirement: Typical Shop Air

General:
Machine Dimensions: Approx. 72″ x 68″ x 95″
Machine Weight: Approx. 4,000 LBS

Equipped With:
Haas CNC Control
CAT-40 Taper Spindle
Automatic Tool Changer
Rigid Tapping
Coolant System
Electronic Handwheel
Programmable Spindle Speeds
Full Enclosure
Compact Footprint Design

Table:
Table Size: 914 mm x 305 mm
Max Table Load: 500 LBS
T-Slots: 3
T-Slot Width: 5/203 mm

Travels:
X-Axis Travel: 406 mm
Y-Axis Travel: 305 mm
Z-Axis Travel: 254 mm

Spindle:
Spindle Taper: CAT-40
Spindle Speed: 6,000 RPM
Spindle Motor: 7.5 HP
Drive Type: Direct Drive

Automatic Tool Changer:
ATC Capacity: 10 Stations
Tool Change Type: Automatic
Max Tool Diameter: Approx. 76 mm
Max Tool Weight: Approx. 12 LBS

Feed Rates:
Rapid Traverse Rate: Approx. 710 IPM
Cutting Feed Rate: Programmable

Electrical:
Power Requirement: 220V / 3-Phase / 60 Hz
Air Requirement: Typical Shop Air

General:
Machine Dimensions: Approx. 1,829 mm x 1,727 mm x 2,413 mm
Machine Weight: Approx. 4,000 LBS
