Kitamura MyCenter 1by485 Vertical Machining Center

Out of stock

SKU:	1034
Make/Model:	Kitamura Mycenter 1/485
Video:	[fusion_button link=”https://www.youtube.com/watch?v=4NHtbKJJ8jc” title=”” target=”lightbox” link_attributes=”” alignment_medium=”” alignment_small=”” alignment=”center” modal=”” hide_on_mobile=”small-visibility,medium-visibility,large-visibility” sticky_display=”normal,sticky” class=”” id=”” color=”default” button_gradient_top_color_hover=”” hue=”” saturation=”” lightness=”” alpha=”” button_gradient_top_color=”” button_gradient_bottom_color_hover=”” button_gradient_bottom_color=”” gradient_start_position=”” gradient_end_position=”” gradient_type=”” radial_direction=”” linear_angle=”180″ accent_hover_color=”” accent_color=”” type=”” bevel_color=”” bevel_color_hover=”” border_top=”” border_right=”” border_bottom=”” border_left=”” border_radius_top_left=”” border_radius_top_right=”” border_radius_bottom_right=”” border_radius_bottom_left=”” border_hover_color=”” border_color=”” size=”” padding_top=”” padding_right=”” padding_bottom=”” padding_left=”” fusion_font_family_button_font=”” fusion_font_variant_button_font=”” font_size=”” line_height=”” letter_spacing=”” text_transform=”” stretch=”yes” margin_top=”” margin_right=”” margin_bottom=”” margin_left=”” icon=”fa-play-circle fas” icon_position=”left” icon_divider=”no” hover_transition=”none” animation_type=”” animation_direction=”left” animation_color=”” animation_speed=”0.3″ animation_delay=”0″ animation_offset=””]Play Video[/fusion_button]

SKU: 1034

Kitamura MyCenter 1by485 Vertical Machining Center
Make	Kitamura
Model No.	Mycenter 1/485
Country of Origin:	Japan
Condition	Very Good

Kitamura MyCenter 1by485 Features:
Fanuc OM Control.
RS-232 Port.
BT35 Spindle Taper.
16-Station Automatic Tool Changer.
Coolant System.

Kitamura MyCenter 1by485 Specifications:
Travel:
X-Axis: 19.15″
Y-Axis: 12.2″
Z-Axis: 18.1″

Table:
Table Dimensions: 31″ x 14″
T-Slots (number x width x distance between centers): 3 x 9/16″ x 4.25″
Maximum Weight on Table: 660 lbs.

Spindle:
Taper: BT35
Speed: 13,000 Maximum RPM
Spindle Center to Column: 15″
Motor (continuous / 30 min.): 5.5 / 7.5 Horsepower

Feed Rates:
Cutting Feed Rate (X, Y, Z,): 0.04 to 157 in/min
Rapid Traverse Rate (X, Y, Z,): 710 / 710 / 550 in/min

Automatic Tool Changer:
Tool Capacity: 16
Maximum Tool Diameter: 3.7″
Maximum Tool Weight: 13.2 lbs.

General:
Machine Weight: 7,500 lbs.
Electrial: 220 Volt, Three Phase
Overall Dimensions: 78″ x 80″ x 105″ tall

Kitamura MyCenter 1by485 Comes as shown in pictures.

GUARANTEE: If any machine guaranteed by us does not prove satisfactory mechanically, the Purchaser may return it freight prepaid within 14 days from date of shipment and we will refund the purchase price in full. This does not apply to machine sold “as is” or “subject to inspection”. This guarantee applies only to machines which we own. The machine must be returned in the same condition that it left our warehouse. MachineStation shall not be responsible for any damage done by truckers, riggers, or other parties. Machine damaged in shipping are not covered under the return privilege.

WARRANTY: Seller makes no warranties of any kind whatever, expressed, or implied. All specifications and descriptions of said goods are approximate, not binding and meant only as a guide. It is the Buyer’s responsibility to inspect the goods and ascertain if the specifications, description and condition of the goods confirm to the Buyer’s requirement.

MACHINE USE AND SAFETY: Buyer acknowledges that the goods described herein are pre-owned used goods which were neither designed or manufactured by the Seller, nor has the Seller knowledge of, or control over, the prior use or misuse of said goods: nor does the Seller have knowledge or control over the application of these goods by the Buyer. It is the Buyer’s (user’s), responsibility to provide proper safety devices, equipment and instructions for any particular use, and to take all necessary steps to confirm to all Federal, State or Local Government Safety Standards and including OSHA.

BUYER IS RESPONSIBLE FOR SCHEDULING TRANSPORTATION OF THIS MACHINE, AS WELL AS ALL COST TO MOVE IT. IF YOU NEED HELP WITH SCHEDULING, PLEASE CONTACT US AND WE WILL ASSIST YOU. WE SHIP GLOBALLY.
