*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Kiwa |
| Model No.: | KMH-300A |
| Year of Manufacture: | 2017 |
| Cutting Time: | 7531 Hours |
| Equipped With: |
|---|
| Fanuc Oi-MF CNC Control |
| 12,000 RPM High Precision Spindle |
| Through Spindle Coolant |
| 6 Pallet Changer |
| 120 Station Automatic Tool Changer |
| Renishaw NC4 Laser Probe |
| Chilled Ballscrews |
| High Speed Machining |
| MPG Handwheel Control |
| PCMCIA Card Slot |
| Pallet Seat Detection |
| Spindle Orientation |
| Rigid Tapping |
| Coolant tank |
| Chip Conveyor |
| Travels: |
|---|
| X Axis: 18.1″ |
| Y Axis: 18.1″ |
| Z Axis: 13.7″ |
| B Axis: 0.001° Indexing (Full 4th Axis) |
| Pallet: |
|---|
| Number of Pallets: 6 |
| Length: 12.6″ |
| Width: 12.6″ |
| Max Weight on Table: 551 lbs |
| Spindle: |
|---|
| Taper Size: 40 |
| Max. Speed: 12,000 RPM |
| Power: 20 HP |
| Feed rates: |
|---|
| Rapid X, Y & Z : 1968 Inch Per Minute |
| Cutting Feedrate: 472 Inch Per Minute |
| Automatic Tool changer: |
|---|
| Capacity: 120 Tools |
| Taper: 40 |
| Max Tool Diameter (Without Adjacent Tool): 6.3″ |
| Max Tool Length: 12.6″ |
| Max Tool Weight: 17.6 lbs. |
| General: |
|---|
| Air Required: 90 psi, 4 scfm |
| Power: 25 kva / 205-220v / 3-Phase |
| Overall Dimensions: 140″ X 121″ x 89.4″ High |
| Weight: 14,000 lbs. Approx. |
