MAZAK VCC 5X 20K 5 AXIS CNC VERTICAL MACHINING

$88,200.00

Specification
Share

Description

MAZAK VCC 5X 20K 5 AXIS CNC VERTICAL MACHINING
SKU 2217
Make MAZAK
Model No. VCC 5X 20K
Serial # 228883
Year
Condition Excellent
Cutting Hours:
  • Features:
  • Mazatrol Matrix 2 CNC Control w/ 19″ Display
  • Simultaneous/Contouring 5 Axis Cutting
  • 20,000 RPM High Precision Spindle
  • Coolant through Spindle
  • Multi-Directional Turn Table
  • 30 Tools High Speed ATC
  • Thermal Compensation
  • MPG Control
  • High Speed Machining
  • Dual USB Slot
  • Spindle Chiller
  • Spindle Orientation
  • Helical Interpolation
  • Rigid Tapping
  • Absolute Incremental Programming
  • Fast Rapid Traverse Rate
  • Flood coolant with large separate coolant tank
  • Dual Chip augers
  • Work light
  • e-Manuals on Disk.
  • Specifications:
  • Travels:
  • X Axis: 20.49″
  • Y Axis: 16.95″
  • Z Axis: 20.04″
  • A Axis: -140° -15° ( Table Tilt )
  • C Axis: 360° ( Table Rotate )
  • Min. Increment: 0.001°
  • Table:
  • Length: 25.7″
  • Width: 15.7″
  • Max Weight on Table: 660 lbs
  • Max Weight on Rotary: 66 lbs
  • T-Slot : 0.6″ X 3 Slots
  • Table to Spindle Nose: 3.9″ – 23.6″
  • Spindle:
  • Taper Size: CAT-40
  • Speed : 20,000 RPM
  • Spindle Power: 30 HP 60NM Torque
  • Table:
  • Length: 25.7″
  • Width: 15.7″
  • Max Weight on Table: 660 lbs
  • Max Weight on Rotary: 66 lbs
  • T-Slot : 0.6″ X 3 Slots
  • Table to Spindle Nose: 3.9″ – 23.6″
  • Feed rates:
  • Rapid X & Y : 1575 Inch Per Minute
  • Rapid Z : 2047 Inch Per Minute
  • Rapid A : 40 RPM
  • Rapid C : 50 RPM
  • Cutting Feedrate: 984 Inch Per Minute
  • Tool changer:
  • Capacity: 30 Tools
  • Taper: 40
  • Max Tool Size: 4.92″ X 7.5″
  • Max Tool Weight: 18 lbs.
  • Tool Change Time: 1.7 Second
  • General:
  • Air Required: 80 psi, 4 scfm
  • Power: 63kva / 205-220v / 3-Phase
  • Overall Dimensions: 120″ X 73″ X 106″ High
  • Weight: 12,000 lbs
