Okuma Cadet LNC10 L1420 CNC Turning Center
Make
Okuma
Model No.
CADET LNC-10
Serial #
0258
Condition
Very Good
Out of stock
| Make | Okuma |
| Model No. | CADET LNC-10 |
| Serial # | 0258 |
| Condition | Very Good |
Add to WishlistRemove from Wishlist
Add to Wishlist
All specifications are approximations and are subject to verification.
| Make | Okuma |
| Model No. | CADET LNC-10 |
| Serial # | 0258 |
| Condition | Very Good |
| Okuma Cadet LNC10 L1420 CNC Turning Center Equipped With: |
|---|
| 12-Station Turret |
| OSP-700L CNC Control |
| One Touch IGF Programming |
| Floppy Drive |
| 12″ Hydraulic Chuck |
| Chip Pan and Chip Conveyor |
| Coolant System |
| Automatic Lubrication system |
| Foot Operated Control for Chuck |
| Okuma Cadet LNC10 L1420 CNC Turning Center Specifications: |
|---|
| Max Turning Diameter: 14.17″ |
| Max Turning Length: 25.29″ |
| Max Bar Capacity: 3.15″ |
| Swing Over Bed: 28.41″ |
| Travel: |
|---|
| X Axis Travel: 9.1″ |
| Z Axis Travel: 25.59″ |
| Rapid Traverse X Axis: 472 IPM |
| Rapid Traverse Z Axis: 591 IPM |
| Spindle: |
|---|
| Spindle Nose: A2-8 |
| Spindle Bore: 3.54″ |
| Spindle Speed: 65-3200 RPM |
| Spindle Motor: 30 HP |
| Turret: |
|---|
| Turret Capacity: 12 Stations |
| Turret Index Time: 1 Second |
| General: |
|---|
| Power Source: AC 220 V, Three Phase, 60 Hz |
| Power Requirement: 68 Amps |
| Overall Dimensions: 126″ x 68″ x 80″ High |
| Overall Dimensions: 150″ x 68″ x 80″ High with Chip Conveyor |
| Weight : 15000 lbs Approx. |
“No Charges for loading at list Price”Okuma Cadet LNC10 L1420 CNC Turning Center Comes as shown in picture…
MachineStation buys sells trade all kinds of new and used CNC metal cutting & metal forming machines …. Used CNC Machines, CNC lathes, CNC mills, presses, gears, turning centers, horizontal machining centers, vertical machining centers, horizontal lathes, vertical lathes, surface grinders, cylindrical grinders, sheets, fabricating equipment, boring mills, lasers cutting, saws, waterjets, shears, press brakes.
| Okuma Cadet LNC10 L1420 CNC Turning Center Equipped With: |
|---|
| 12-Station Turret |
| OSP-700L CNC Control |
| One Touch IGF Programming |
| Floppy Drive |
| 305 mm Hydraulic Chuck |
| Chip Pan and Chip Conveyor |
| Coolant System |
| Automatic Lubrication system |
| Foot Operated Control for Chuck |
| Okuma Cadet LNC10 L1420 CNC Turning Center Specifications: |
|---|
| Max Turning Diameter: 360 mm |
| Max Turning Length: 642 mm |
| Max Bar Capacity: 80 mm |
| Swing Over Bed: 722 mm |
| Travel: |
|---|
| X Axis Travel: 231 mm |
| Z Axis Travel: 650 mm |
| Rapid Traverse X Axis: 472 IPM |
| Rapid Traverse Z Axis: 591 IPM |
| Spindle: |
|---|
| Spindle Nose: A2-8 |
| Spindle Bore: 90 mm |
| Spindle Speed: 65-3200 RPM |
| Spindle Motor: 30 HP |
| Turret: |
|---|
| Turret Capacity: 12 Stations |
| Turret Index Time: 1 Second |
| General: |
|---|
| Power Source: AC 220 V, Three Phase, 60 Hz |
| Power Requirement: 68 Amps |
| Overall Dimensions: 3,200 mm x 1,727 mm x 2,032 mm High |
| Overall Dimensions: 3,810 mm x 1,727 mm x 2,032 mm High with Chip Conveyor |
| Weight : 15000 lbs Approx. |
| Make | Okuma |
|---|
