Sharp LMV50 Vertical Milling Machine

Share

Description

Sharp LMV50 Vertical Milling Machine
Make Sharp
Model No. LMV-50
Condition New
  • Sharp LMV50 Features:
  • DVS Head For:
  • High reliability with fewer moving parts than regular vari-speed head
  • Dynamic brake
  • Low voltage control
  • Large Digital RPM Display
  • Fully enclosed display unit
  • Dependable Inverter Drive System
  • Machine can run on single phase or 3 phase electricity
  • Safety device prevents machine from self starting after power failure or after emergency stop being pushed
  • Sharp LMV50 Optional Accessories: (Please call for pricing and additional information)
  • Power Feeds for  Saddle and Knee
  • R-8 Collet Set
  • Milling Vise
  • Clamping Kit
  • Coolant System with Chip Pan
  • Right Angle Milling Attachment
  • Riser Block (4″, 7″)
  • Power Drawbar
  • Auto Lube System
  • Halogen Work Light.
  • Sharp LMV50 Specifications:
  • Table:
  • Working Surface: 9″ x 50″
  • T-Slot Number, Size: 3, 5/8″
  • Capacity:
  • Table Travel (X-Axis): 37″
  • Saddle Travel (Y-Axis): 12″
  • Quill Travel (Z-Axis): 5″
  • Ram Travel: 12″
  • Knee Travel: 16″
  • Spindle to Column (min-max): 6-3/4″ – 18-1/2″
  • Spindle Nose to Table (min-max): 2-1/8″ – 18″
  • Spindle:
  • Motor: 3 HP
  • Wiring Voltage: 220/440V, 3 phase, 60 Hz
  • Taper: R-8
  • Speed (Vari-speed): 60 – 4,500 RPM
  • Quill Feed (IPR): 0.0015″, 0.003″, 0.006″
  • Head Swivel: 360 Degrees
  • Head Tilt (Right to left each way): 45 Degrees
  • Head Tilt (Up and down each way): 45 Degrees
  • Dimensions & Weight:Floor Area (WxDxH): 7′ x 6-1/2′ x 6-3/4′
  • Net Weight (approx.): 2,400 lbs
  • Sharp LMV50 Standard Equipment:
  • Digital Variable Speed Head
  • Power Feed on X Axis
  •  3 Axis DRO
  • Hard-chromed ways
  • One-shot lube system
  • Front and rear rubber way covers
  • Tool Kit
