USED-Logan Variable Speed Bench Engine Lathe |
|
|---|---|
| Make | Logan |
| Country of Origin: | USA |
| Condition | Very Good |
- Features:
- L00 Spindle Nose.
- 6″ Three-Jaw Chuck.
- Infinitely Variable Spindle Speeds.
- Specifications:
- Capacities:
- Swing Over Bed: 12″
- Swing Over Cross Slide: 7″
- Swing Over Compound Slide: 1-1/2″
- Distance Between Centers: 36″
- Spindle:
- Thru Hole: 1-3/8″
- Height from Floor to Center: 45-1/2″
- Number of Speeds: Infinitely Variable
- Speed Range: 40 to 1,400 rpm
- Carriage:
- Cross Slide Travel: 10″ approx.
- Compound Slide Travel: 4″ approx.
- Threads:
- Inch: 4 to 224
- Tailstock:
- Spindle Taper: #2 Morse Taper
- Spindle Diameter: 1-3/8″
- Spindle Travel: 3-1/2″
- Bed:
- Width: 7″
- Length: 55″
- General:
- Motor: 1 Horsepower, 220 / 440 Volt, 1,800 RPM, 3 / 1.5 Amps, 60 Hz
- Electrical: 220 / 440 Volt, Three Phase
- Overall Dimensions: 71″ x 23″ x 50″ tall
USED-Logan Variable Speed Bench Engine Lathe and Comes as shown in pictures.
